Trammell came across a cache of punched paper tape recently. My immediate impulse was to create the most primitive tape reader possible. Thusly:
The rig is composed of a Teensy++ 2.0, eighteen red LEDs, eighteen resistors, and a few bits of laser-cut plastic. LEDs are used to both illuminate the paper and sense the holes. The sensor design is based on the classic Arduino LED sensing code. It’s not very reliable, but it’s a fun afternoon proof-of-concept.
If you’re interested, the code and design files are up on github.
